Description

VECTRONIC Aerospace has developed the VRW-05 reaction wheel series especially for small satellite applications. Reaction wheels are actuators used to influence the rotational motion of a spacecraft. According to the principle of angular momentum conservation, a torque is exerted onto the spacecraft if the wheel speed is changed. The ratio between acceleration of the wheel and the spacecraft is equal to the ratio of their moments of inertia.

The wheel speed is controlled with a model supported PI-loop running inside the 32-bit microprocessor which is using a low noise high efficiency four quadrant PWM method in the power stage. The wheel drive electronic includes thermal and over voltage protection circuits. The signal interface is a standard asynchronous SCI on RS422/RS485 level. It can be used in a single full-duplex configuration as well as in a half-duplex bus architecture. The baud rate is adjustable up to 1Mbaud. A CAN bus interface is also available.

The reaction wheel design is kept modular. By changing the rotor geometry, input voltage range or communication protocol, the VRW-05 characteristics are easy to adapt to customer needs. Flexible operation in torque control mode or speed control mode is possible.

The nominal In-Orbit lifetime for this type of reaction wheels is more than 45.000 hours.
Beside the nominal angular momentum of 0.5 Nms, the VECTRONIC portfolio also provides reaction wheels with 0.2, 1, and 2 Nms.



Datasheet

Vectronic Aerospace – VRM-05

Overview
NameVRM-05
ManufacturerVectronic Aerospace
SubsystemACDS
ClassificationReaction Wheel
Form FactorSmallSat
TRL9
HeritageYes
Vendor Overview
Vendor NameVectronic Aerospace
Vendor Websitehttps://vectronic-aerospace.com/
Vendor LocationGermany
Vendor Request for Information Form
Name *

Email *

Country *

Would you like suggestions about similar products/services from other suppliers?

Inquiry Description *

SPECIFICATIONS
SubsystemACDS
ClassificationReaction Wheel
Form FactorSmallSat
VendorVectronic Aerospace
HeritageYes
Mass1.3 kg
Nominal Power3.0 W
