T-717 X-Band Transmitter
Overview
Model T-717 is a QPSK or OQPSK high-rate transmitter with a parallel LVDS interface. The unit is optimized for the 8.0 to 8.4 GHz band and maintains an EOL output power of 8 Watts. The solid-state power amplifier contains a bandpass filter providing NTIA spectral emissions compliance. Using the LVDS interface, the unit is designed for data rates up to 150 Mbps per channel (I and Q) with NRZ-L to NRZ-M conversion. Additionally, at less than 8.5 lb., the T-717 is designed for mission durations greater than 5 years with a minimum tolerance of 60 kRad behind 100 mils of shielding.
Looking for more information or want to purchase?
Overview
- Name
- T-717 X-Band Transmitter
- Vendor
- L3Harris Technologies
- Subsystem
- Telecom Subsystem
- Component Type
- Transmitter
- Form Factor
- SmallSat
- Heritage
- Yes
Vendor Details
- Name
- L3Harris Technologies
- Website
- https://www.l3harris.com/
Vendor Request for Information Form
Specifications
- Subsystem
- Telecom Subsystem
- Component Type
- Transmitter
- Form Factor
- SmallSat
- Vendor
- L3Harris Technologies
- Dry Mass
- 3.85 kg
- Average Power
- N/A
- Heritage
- Yes
- Status
- In Production
