Separation Nut PSM 1/2B

Separation Nut PSM 1/2B image

Overview

The Beyond Gravity PSM 1/2B Separation Nut is the medium member of our family of Low Shock Separation Nuts designed for interfacing medium sized spacecraft with Launcher Vehicles. It has been developed to fit constellation class satellites, typical 500-1000 kg.


The Beyond Gravity PSM 1/2B introduces an internal mechanical leverage minimizing the required pressure spike generated by the initiators. Hence the shock is significantly reduced without sacrifice of reliability compared with heritage separation nuts. The separation nut avoids metals with different thermal expansion coefficients to achieve a wide thermal operation range. It has been designed as a direct drop in replacement for many of the classical higher shock separation nuts.

Looking for more information or want to purchase?

Overview

Name
Separation Nut PSM 1/2B
Component Type
Mechanism
Form Factor
SmallSat
Heritage
Yes

Vendor Details

Name
Beyond Gravity
Founded
2009
Summary
Beyond Gravity (formerly RUAG Space) is a pioneer in the space industry, fusing the nimbleness, creativity, and inventiveness of a startup with a wealth of expertise and a reputation for quality. Our primary objective is to push the boundaries of human achievement and facilitate exploration of the cosmos by developing and producing cutting-edge satellite and launch vehicle technologies. We are the go-to provider of structural components for all types of launch vehicles and a top player in the development of satellite products and constellations in the burgeoning New Space field.

Vendor Request for Information Form

Max. 1000 characters

Please include a detailed description in your message. This helps vendors to better understand your request.

Specifications

Component Type
Mechanism
Form Factor
SmallSat
Dry Mass
0.43 kg
Average Power
N/A
Heritage
Yes
Status
In Production
