Raptor Imager
Overview
The Raptor is a high-performance Earth observation system with high supervision capabilities in panchromatic imaging. The Raptor imager covers very high spatial resolution and allows detailed earth imaging and precise mapping for key civilian or security applications.
Looking for more information or want to purchase?
Overview
- Name
- Raptor Imager
- Vendor
- Dragonfly Aerospace
- Subsystem
- Payload Subsystem
- Component Type
- Camera/Imager
- Form Factor
- SmallSat
- Heritage
- N/A
Details
- TRL
- 5
- Spatial resolution (GSD) at 500 km - Native
- 0.5 m
- Spatial resolution (GSD) at 500 km - Super-Resolution
- 0.36m
- Swath at 500 km
- 8 km
- Imager Type
- Push broom
- Spectral Bands
- 6 x MS plus 2x PAN
Vendor Details
- Name
- Dragonfly Aerospace
- Website
- https://dragonflyaerospace.com/
- Founded
- 2020
- Summary
- Dragonfly Aerospace envisions a future in which our small, high-performance imaging satellites and payloads enable large imaging constellations that provide persistent views of the Earth in a variety of spectrums, providing unprecedented business intelligence and improving people's lives all over the world. Dragonfly Aerospace satellites and payloads are built on a 25-year legacy of components and design principles that date back to the first South African microsatellite, SUNSAT, which was launched in 1999. Since South Africa's entry into the space race, members of our team have worked on every microsatellite space mission.
Vendor Request for Information Form
Specifications
- Subsystem
- Payload Subsystem
- Component Type
- Camera/Imager
- Form Factor
- SmallSat
- Vendor
- Dragonfly Aerospace
- Dry Mass
- 55.0 kg
- Average Power
- 45.0 W
- Heritage
- N/A
- Status
- In Production
