PowerCube: 1U 100W Solar Array

PowerCube: 1U 100W Solar Array image

Overview

Deployable 100W Origami solar array for high-power space missions, stowed within a 1U form factor.


The DCUBED PowerCube is a deployable 100W Origami Solar Array stowed within a 1U form factor. PowerCube enables extremely power-intensive space missions while requiring only minimal stowed volume during launch. It is one of the smallest, yet powerful solar array solutions on the market. It is easily resettable, easy-to-use and readily available as a COTS subsystem.


See how the DCUBED PowerCube works here: https://www.youtube.com/watch?v=9l_64LF0Kv8&t=4s


Key Features
Short Delivery Time (12 months)
EOL power: 100 W (5 years lifetime)
Stowed volume: 100x100x100 mm (1U)
Deployed volume: 110x110x190 mm
Mass 1.2 Kg
Bus voltage: 14-28 V
Redundant actuation
Compliant with the CubeSat standard


Export Control
The DCUBED Origami Solar Array is ITAR Free.

Looking for more information or want to purchase?

Overview

Name
PowerCube: 1U 100W Solar Array
Vendor
DCUBED
Component Type
Solar Panel
Form Factor
CubeSat
Heritage
N/A
Average Lead Time
6 to 12 months

Vendor Details

Name
DCUBED
Founded
2019
Summary
Dcubed is a NewSpace company located in Germany and the United States. Dcubed accelerates space exploration by developing and manufacturing user-friendly, durable, and affordable Release Actuators and Solar Arrays for a wide range of space applications. Dcubed’s space-proven Launch Locks and Release Actuators (Pin Pullers and Release Nuts) are readily available (lead times of only a few weeks), easy to use, and field-resettable of up to a few hundred times. Furthermore, Dcubed’s space-proven Solar Arrays, tackle the needs of global space customers, namely maximizing performance in space, while efficiently stowing in a standardized volume for launch. Dcubed develops body-mounted, deployable and rollable Solar Arrays to cover an array of power requirements. Partner with Dcubed and let’s do Big Things in Space!

Vendor Request for Information Form

Max. 1000 characters

Please include a detailed description in your message. This helps vendors to better understand your request.

Specifications

Component Type
Solar Panel
Form Factor
CubeSat
Vendor
DCUBED
Dry Mass
1.2 kg
Average Power
100.0 W
Heritage
N/A
Status
In Production
