Payload Support Unit (PLSU)
Overview
The Payload Support Unit (PLSU) by Berlin Space Technologies is a sophisticated electronic device that is designed to operate a payload, receive, store, process and compress payload data. It further includes an encryption and CCSD engine. Additional functions are to monitor and compensate the temperature of a payload and operate a focus mechanism.
Specifications:
Input from payload:
- Up to 10 Gbit/s raw
- LVDS, Camera Link, GigE, USB
Processing:
- User defined processing (FPGA)
- Geometric and radiometric corrections
- TDI (Image stacking) for increased SNR
- JPEG compression
- H.264 Video Compression
Storage:
- 1 TB storage
- 850 MByte/s write speed
Encryption:
- 128 bit AES in Counter Mode
- Diffi-Hellman - RSA Key 3072 bit (longer key length on request)
Output:
- Up to 10 Gbit/s data input (raw)
- User defined interfaces (FPGA)
- LVDS, GigE, USB
Looking for more information or want to purchase?
Overview
- Name
- Payload Support Unit (PLSU)
- Vendor
- Berlin Space Technologies
- Subsystem
- Payload Subsystem
- Component Type
- Special Payload
- Form Factor
- SmallSat
- Heritage
- Yes
Vendor Details
- Name
- Berlin Space Technologies
- Founded
- 2009
- Summary
- Berlin Space Technologies (BST) is a specialist for small satellite systems and technology. We build on a 30 year tradition of small satellites made in Berlin. BST is vertically integrated and offers reliable and cost-efficient end to end solutions for your mission. Berlin Space Technologies (BST) is a global leader in the NewSpace economy and an experienced supplier of small satellite systems and technologies. Our subsystems fly on more than 100 missions and our state of the art LEOS platform can support the most challenging missions. We are an vertical integrated end to end solution provider. We offer capacity building for emerging space nations, in orbit demonstration for your payloads and together with our partner Azista we can provide entire mega constellations.
Vendor Request for Information Form
Specifications
- Subsystem
- Payload Subsystem
- Component Type
- Special Payload
- Form Factor
- SmallSat
- Vendor
- Berlin Space Technologies
- Dry Mass
- N/A
- Average Power
- N/A
- Heritage
- Yes
- Status
- In Production
