OBC Veng/CONAE
Overview
The flight computer (OBC), developed jointly by CONAE and VENG S.A., is a complex electronic unit, developed to manage satellite mission instruments, with data transfer rates of up to 100 Mbps, in addition to providing general-purpose RS-422 bi-level interfaces, analog channels for the acquisition of voltages and temperatures (housekeeping information, both internal to the unit and external) and the ability to command up to 24 heaters, through opto-coupled outputs.
It has a power module, a module based on the 32-bit UT699 LEON3-FT processor and 6 additional functional modules, all linked through the cPCI 2.2 standard using a Backplane. In addition, it has an additional slot, designed to adapt to the needs of different missions/projects.
Looking for more information or want to purchase?
Overview
- Name
- OBC Veng/CONAE
- Vendor
- VENG S.A.
- Subsystem
- CDH Subsystem
- Component Type
- On-Board Computer
- Form Factor
- All
- Heritage
- N/A
- Average Lead Time
- 60 months
Vendor Details
- Name
- VENG S.A.
- Website
- https://veng.com.ar/en/
- Founded
- 2007
- Summary
- VENG offers to the space industry and to the high tech consumer industry in general, engineering and manufacturing services targeted at solving complex problems.
Vendor Request for Information Form
Specifications
- Subsystem
- CDH Subsystem
- Component Type
- On-Board Computer
- Form Factor
- All
- Vendor
- VENG S.A.
- Dry Mass
- 7.5 kg
- Average Power
- 40.0 W
- Heritage
- N/A
- Status
- Unknown
