HDRTx-3

Vendor profile

Overview

The HDRTx-3 is a dual-channel X-band transmitter tailored for micro and mini satellites in low Earth orbit.

Featuring advanced DVB-S2 encoding, it maximizes data throughput, with each channel supporting symbol rates of up to 300 Msps for reliable, high-performance communication in space missions

Looking for more information or want to purchase?

Contact now

Overview

Name: HDRTx-3
Vendor: Dragonfly Aerospace
Subsystem: Telecom Subsystem
Component Type: Transmitter
Form Factor: All
Heritage: N/A

Details

Design Life: Up to 8 years LEO
Dimensions: 175 x 145 x 55 mm
HIgh-Speed Data Interfaces: GTx, LVDS
Operating Temperature: -10 °C to +50 °C
Power Consumption (Configuration Dependent): < 36 W
RF Frequency Range: 8.025-8.4 GHz
Supply Voltage: 20-40 V
TMTC Interface: CAN, I²C, RS485

Vendor Details

Name: Dragonfly Aerospace
Website: https://dragonflyaerospace.com/
Founded: 2020
Summary: Dragonfly Aerospace envisions a future in which our small, high-performance imaging satellites and payloads enable large imaging constellations that provide persistent views of the Earth in a variety of spectrums, providing unprecedented business intelligence and improving people's lives all over the world. Dragonfly Aerospace satellites and payloads are built on a 25-year legacy of components and design principles that date back to the first South African microsatellite, SUNSAT, which was launched in 1999. Since South Africa's entry into the space race, members of our team have worked on every microsatellite space mission.
