Garnet Pressure Transducer

Vendor profile

Overview

The Garnet propellant measurement unit combines pressure and temperature sensing as well as the signal conditioning electronics. Designed as a seamless plug-and-play subsystem, it serves the critical function of assessing propellant levels from tank pressure and temperature throughout the lifecycle and particularly at end-of-life stages.

The unit comes in multiple configurations ensuring compliance to common satellite propellants, fluidics and avionics interfaces.

= PERFORMANCE =
- Pressure range (MEOP): 0 ... 10 bar, 30 bar, 100 bar, 200 bar, 320 bar
- Proof pressure: 1.5 x MEOP
- Burst pressure: 4 x MEOP
- Accuracy: ±0.25% FS
- Temperature sensing: internal and/or external thermistor

= INTERFACE =
- Supply voltage: 8 V - 34 VDC
- Current consumption: < 10 mA
- Output interface: 0 V - 5 V (analog)
- Mechanical interface: 2 x M3 fasteners
- Size: 62 mm x 36 mm x 36 mm
- Mass: starting from 110g

= ENVIRONMENTAL =
Temperature range (operational): -30 °C to +60 °C operational
Temperature range (non-operational): -40 °C to +70 °C operational
Radiation: TID > 30 krad, SEL immune
Random vibration: 14.1 grms
Shock: SRS 1000g (ECSS-E-ST-10-03C)
Compatibility: MON, MMH, ADN, HAN, HTP, N2O, Water, He, N2, Xe, Kr, Ar

Looking for more information or want to purchase?

Contact now

Overview

Name: Garnet Pressure Transducer
Vendor: Ascend Beyond Space
Subsystem: Other
Component Type: Other
Form Factor: All
Heritage: N/A
Average Lead Time: 2 to 6 months

Details

Fluidic Interfaces Options: 1/4" weldable tube | VCR |Swagelok Tube Fitting
Electrical Interfaces Options: Flying leads | Nicomatic DMM | Nano-D-Sub
Wetted Material Options: AISI 316L | Ti-6Al-4V | Hastelloy C-276
Analysis Performed: PSA, WCA, FIT, Structural

Vendor Details

Name: Ascend Beyond Space
Website: https://www.ascendbeyond.space/
Founded: 2024
Summary: Ascend Beyond Space is a provider of advanced power, fluidics and propulsion subsystems for satellites with a strong focus on sustainable use of space and disposal of satellites at the end of their missions. The company offers the first complete and accessible ecosystem of compatible and complementary equipment designed for this purpose, providing a sustainable solution to the growing challenge of space debris.
