FPPT 1U
Overview
Engineers at CUA have developed a patented Fiber-fed Pulsed Plasma Thruster (FPPT) which consumes PTFE propellant from a spooled form. The thruster uses massive parallelism in its energy storage unit (ESU) design, assembling COTS components into discrete modular capacitor assemblies while maintaining low per-cap specific current levels. Discharge initiation is accomplished via a regenerative carbon igniter array located in the thruster cathode. Thruster performance varies with fuel feed rate, with 16 J ESU configuration measured values ranging from 0.12 mN-s at 1,000 s to 0.09 mN-s at 1,700 s. Higher specific impulse of 2400 s was measured in a 32 J configuration. A 1U design provides up to 5,500 N-s total impulse while a 1.7U design provides up to 15,000 N-s total impulse. Accelerated subsystem life testing demonstrated > 1.6 billion capacitor charge / discharge cycles with nearly identical specific current waveforms. FPPT utilizes the completely non-toxic solid propellant Teflon with benign exhaust, has no corrosive or propellant plugging issues, and has on-demand thrust with no warmup time requirement. Further, the ability to control both input power and propellant feed rate allows tuning from higher-Isp operation to higher-thrust operation. CUA believes that the FPPT technology is a compelling option to meet many micropropulsion needs including deep-space missions.
Looking for more information or want to purchase?
Overview
- Name
- FPPT 1U
- Vendor
- Champaign-Urbana Aerospace
- Subsystem
- Propulsion Subsystem
- Component Type
- Electric Propulsion System
- Form Factor
- CubeSat
- Heritage
- N/A
- Average Lead Time
- 9 months
Vendor Details
- Name
- Champaign-Urbana Aerospace
- Website
- https://cuaerospace.com/
Vendor Request for Information Form
Specifications
- Subsystem
- Propulsion Subsystem
- Component Type
- Electric Propulsion System
- Form Factor
- CubeSat
- Vendor
- Champaign-Urbana Aerospace
- Dry Mass
- 1.21 kg
- Average Power
- 48.0 W
- Heritage
- N/A
- Status
- In Production
