300 GHz Transceiver
Overview
ACST 300 GHz transceiver for FMCW radar is designed and manufactured as a bench top unit. It takes an input signal at 11.45 GHz to 13.12 GHz to reach 275 to 315 GHz for the Tx and LO power at 137.5-157.5 GHz for the Rx. A dedicated directional coupler is used to separate the transmitter and receiver LO paths. The typical transmitting power is +14 dBm and 8.5 dB DSB noise figure receiver performance. The transceiver assembly is fixed tuned and does not require any adjustment for proper operation. A dedicated power supply is included. Additional options can be implemented on customer request i.e. TTL modulation port, customized IF-band, horn antennas, different multiplication factor of the AMC, etc.
Looking for more information or want to purchase?
Overview
- Name
- 300 GHz Transceiver
- Vendor
- ACST
- Subsystem
- Telecom Subsystem
- Component Type
- Transceiver
- Form Factor
- SmallSat
- Heritage
- N/A
Vendor Details
- Name
- ACST
- Website
- https://acst.de/
- Founded
- 2006
- Summary
- Schottky technology based component, module and system provider. >10 years of cooperation in ESA development programs. Supplier on component and module level for MetOp-SG.
Vendor Request for Information Form
Specifications
- Subsystem
- Telecom Subsystem
- Component Type
- Transceiver
- Form Factor
- SmallSat
- Vendor
- ACST
- Dry Mass
- N/A
- Average Power
- N/A
- Heritage
- N/A
- Status
- In Production
